The HaiDa HD680L-B is a high precision energy saving servo injection molding machine manufactured by Ningbo Haida Plastic Machinery Co., Ltd. specially designed with wider opening stroke for the production of buckets with/without IML. With extended opening stroke, the producer of paint buckets will able to produce an 33L paint buckets with a Haida HD700U injection molding machine.
| DESCRIPTION | UNIT | HD680L-B |
|---|---|---|
| Screw diameter | mm | 90 |
| Screw ratio | 23 | |
| The Injection Rate | g/s | 580 |
| Injection pressure | Mpa | 180 |
| Clamping force | kN | 6800 |
| Opening stroke | mm | 940 |
| Space between tie bar | mm x mm | 940 x 920 |
Adopt high performance hydraulic system, choose famous brand electro-hydraulic proportional valve, meet the manipulator to open die stop position of the harsh requirements, the use of excellent experience.
High rigidity frame, open outlet, reserve full automatic operation space and plan, adapt to high intensity production requirements.
Professional injection molding machine control system, large brand high-performance electronic components.
Large die opening stroke, high strength die closing structure, suitable for the special needs of barrel mold.
Screw special design, strong plasticizing ability, short molding cycle, long service life.
